Researchers at Nagoya University have developed a groundbreaking artificial intelligence system capable of predicting the orientation of crystal grains in polycrystalline materials through optical imagery. This process significantly cuts down the analysis duration from 14 hours to merely 1.5 hours. Published in APL Machine Learning, this advancement holds immense potential for transforming electronics and solar energy sectors.
The Japanese team has created an AI tool for swiftly determining the orientation of crystals in various industrial materials, enhancing the efficiency of polycrystalline components in technological applications.
A group from Nagoya University, led by experts in engineering and informatics, has achieved a notable development in crystal orientation prediction. They have trained an AI model using optical images of polycrystalline materials, a study that has been featured in APL Machine Learning.
The Role of Crystals in Industrial Applications
Crystals are crucial in the construction of numerous devices. Common industrial materials comprising polycrystalline components are metal alloys, ceramics, and semiconductors. Since polycrystals are composed of multiple crystals, they exhibit a complex microstructure with properties that vary based on crystal grain orientation. This aspect is particularly crucial for silicon crystals used in devices like solar cells, smartphones, and computers.
An illustration showing the crystal grain orientations as predicted by the AI technique, where color indicates grain orientation. Credit to Dr. Takuto Kojima.
Examining Polycrystalline Materials: The Challenges
Professor Noritaka Usami emphasizes the need for control and measurement of grain orientation distribution in creating industrially viable polycrystalline materials. The traditional methods, however, are hindered by their costly equipment and lengthy processes needed to measure large samples.
Pioneering AI Use in Predicting Crystal Orientation
The team from Nagoya University, including Professor Usami and Professor Hiroaki Kudo, collaborated with RIKEN in applying a machine learning model. This model assesses images captured by shining light on polycrystalline silicon materials from different angles, successfully predicting grain orientation distribution.
For this purpose, multiple photographs were taken by illuminating a multicrystalline silicon material from various angles. These images were then used to train the machine learning model. Credit to Dr. Takuto Kojima.
Efficiency and Industrial Implications
Professor Usami notes that the AI method requires approximately 1.5 hours for taking photos, training the model, and predicting orientation. This is a significant improvement over the traditional 14-hour methods, also enabling the measurement of large materials, previously unfeasible.
Professor Usami is optimistic about the industrial application of this technique, asserting its potential to revolutionize material development. The research aims to benefit all researchers and engineers working with polycrystalline materials. The possibility of creating an analysis system for polycrystalline materials, incorporating image data collection and a machine learning-based orientation prediction model, is anticipated to be widely adopted by relevant companies.
The study is detailed in “A machine learning-based prediction of crystal orientations for multicrystalline materials” by Kyoka Hara, Takuto Kojima, Kentaro Kutsukake, Hiroaki Kudo, and Noritaka Usami, published on 24 May 2023 in APL Machine Learning.
DOI: 10.1063/5.0138099
