The subterranean terrain beneath the greater New York City area, featuring the borough of Queens as an example, is exhibiting minuscule shifts annually. These changes are attributed to both the historical impact of glaciation and current human land utilization practices. Credit: NASA/JPL-Caltech
Researchers employing satellite-based radar technology have ascertained that New York City’s land is undergoing both subsidence and elevation at disparate rates, influenced by both anthropogenic and natural factors. Certain areas are experiencing an increase in elevation.
A new scientific inquiry, published in Science Advances on September 27, was spearheaded by a multidisciplinary team from NASA’s Jet Propulsion Laboratory (JPL) in Southern California and Rutgers University in New Jersey. The team utilized a specialized remote sensing method known as interferometric synthetic aperture radar (InSAR) to assess the vertical land movement, or uplift and subsidence, in the metropolitan region from 2016 to 2023. This technique amalgamates multiple 3D observations of identical regions to delineate surface activity or geological features.
Cartographic representations of vertical land movements throughout the New York City metropolitan zone revealed an average subsidence rate of about 0.06 inches (1.6 millimeters) per annum. The study also identified modest elevational gains, primarily in Queens and Brooklyn. White dotted demarcations indicate administrative boundaries of counties and boroughs. Credit: NASA/JPL-Caltech/Rutgers University
Table of Contents
Factors Contributing to Land Movement
Significant portions of the observed motion transpired in locales that have previously undergone alterations, such as landfill construction and land reclamation, resulting in a more compressible and unstable subsoil for ensuing structures.
Certain movements are also the consequence of geological processes that trace back to the last ice age approximately 24,000 years ago. At that time, immense ice sheets engulfed much of New England, and a towering ice wall enveloped the current area of Albany, New York. The Earth’s mantle has been undergoing gradual adjustments since then. New York City, positioned on terrain elevated by the ice sheet’s periphery, is currently experiencing a downward trend.
Detailed Observations and Implications
The research team found that the metropolitan area is sinking at an average rate of 0.06 inches (1.6 millimeters) per year. Using ESA (European Space Agency) Sentinel-1 satellites and advanced data analytics, they generated intricate motion maps, identifying particular neighborhoods and landmarks—including airport runways and sports facilities—that are subsiding more rapidly than the regional average.
Specific areas of significant subsidence include runway 13/31 at LaGuardia Airport in Queens, with a subsidence rate of approximately 0.15 inches (3.7 millimeters) per annum. Another point of interest is Arthur Ashe Stadium, which is sinking at about 0.18 inches (4.6 millimeters) per year, necessitating a lightweight roof installation during its refurbishment to mitigate further sinking.
Notable Anomalies
Two areas of pronounced subsidence were identified in proximity to landfills in Queens. Other locations with noteworthy subsidence include Governors Island, constructed from early 20th-century subway excavation debris; portions of Brooklyn’s Coney Island and Arverne by the Sea in Queens, which were built on artificial fill; and Route 440 and Interstate 78 in suburban New Jersey, situated on historical landfill sites.
Previously unobserved uplift was detected in East Williamsburg, Brooklyn, and in Woodside, Queens. According to co-author Robert Kopp of Rutgers University, activities like groundwater extraction and the use of injection wells for pollution remediation may contribute to these phenomena, although further research is required.
Strategic Implications and Future Monitoring
Such high-resolution data on land movement can be highly beneficial for cities like New York, which are investing heavily in coastal defenses and infrastructural projects in anticipation of sea level rise. The OPERA project led by JPL aims to provide comprehensive surface displacement data across North America, leveraging InSAR data from ESA’s Sentinel-1 and the forthcoming NISAR mission scheduled for a 2024 launch. This information will facilitate better understanding and monitoring of vertical land movements and other naturally occurring hazards.
Reference: “Localized uplift, widespread subsidence, and implications for sea level rise in the New York City metropolitan area” by Brett Buzzanga, David P.S. Bekaert, Benjamin D. Hamlington, Robert E. Kopp, Marin Govorcin and Kenneth G. Miller, published on 27 September 2023 in Science Advances.
DOI: 10.1126/sciadv.adi8259
Frequently Asked Questions (FAQs) about Vertical Land Movement in New York City
What is the main focus of the research conducted by NASA and Rutgers University?
The research primarily aims to understand the vertical land movements in the New York City metropolitan area. It examines the rates at which different parts of the city are sinking or rising, employing advanced radar technology known as interferometric synthetic aperture radar (InSAR).
Who conducted the study and where was it published?
The study was carried out by a team of researchers from NASA’s Jet Propulsion Laboratory (JPL) in Southern California and Rutgers University in New Jersey. The findings were published in the journal Science Advances on September 27.
What are the factors causing the land to move in New York City?
The land movement is attributed to both natural and anthropogenic factors. Natural factors include geological processes dating back to the last ice age, while human factors involve land-use practices such as land reclamation and landfill construction.
What technology was used to gather data for the study?
The study employed a remote sensing technique called interferometric synthetic aperture radar (InSAR). This technology combines multiple 3D observations of a given region to map surface movements and topographical changes.
How could this research be useful for urban planning and flood risk management?
The high-resolution data on vertical land movements is crucial for cities like New York that are investing in coastal defenses and infrastructure improvements. Understanding these movements helps in better flood mapping, planning, and risk assessment.
Were any specific areas in New York City found to be at higher risk?
Yes, areas such as runway 13/31 at LaGuardia Airport in Queens and Arthur Ashe Stadium were identified as experiencing more rapid subsidence. These are considered hot spots requiring special attention for future planning.
What are the future plans for monitoring land movements?
The JPL-led OPERA project aims to provide detailed surface displacement data across North America, leveraging InSAR data from ESA’s Sentinel-1 and the forthcoming NISAR mission scheduled for 2024. This will facilitate better monitoring of land movements and other natural hazards.
Are there any other cities undergoing similar studies?
The text does not specify whether other cities are undergoing similar studies, but it does indicate that high-resolution estimates of land motion could benefit cities investing heavily in coastal defenses and infrastructure in the face of sea level rise.
